48 Volt Onboard Battery Charger - 48V 15AMP Lithium, LiFePO4, Lead Acid, AGM Battery Charger
48 Volt Onboard Battery Charger - 48V 15AMP Lithium, LiFePO4, Lead Acid, AGM Battery Charger
Safety & Reliability in Every Charge
Set It & Forget It
Set It & Forget It
- 5 Stage Smart Charge Technology
- SMARTSENSE Maintenance Mode
Advanced WeatherShield Coating
Advanced WeatherShield Coating
- Protects Against Water, Dust & Corrosion
- IP67 Waterproof
SparkGuard Technology
SparkGuard Technology
- Automatically cuts the voltage when disconnected from your cart
Compatible Golf Carts
Compatible Golf Carts
All 48V Golf Carts
Couldn't load pickup availability
- Free Shipping & Returns
5-Year Extended Warranty
Designed In Minnesota
Technical Specs
Technical Specs
Current: 15 Amps DC
Voltage: 48 Volts
Battery Type Supported: Flooded Lead Acid, Lithium, AGM
AC Input Cord: 8ft
DC Output Cord: 8ft
Dimensions
Dimensions
Width: 10"
Depth: 5.25"
Height: 3"
Weight: 5.5 lbs
Safety Features
Safety Features
- Short-Circuit: Yes
- Overheating: Yes
- Overcharge: Yes
- Spark-Proof: Yes
- Reverse Polarity: Yes
Certifications
Certifications
- FCC (Federal Communications Submission)
- DOE (Department of Energy)
- CEC (California Energy Commission)
Federal Communications Commission (FCC) statement
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at his own expense.
In The Box
In The Box
- Charger with 8ft AC input cord & 8ft DC output cord with Club Car Circle Plug
- Product Manual
Product Manual
Product Manual
Troubleshooting
Troubleshooting
FAQ'S
We do not recommend leaving your FORM charge charger plugged in for more than 30 days without checking on it. While FORM Charge has built-in safeguards, extended charging can lead to issues like battery drying or cell failure, which may damage the battery.
To protect your batteries during long-term storage, it's best to fill lead-acid batteries with distilled water, switch the cart to tow mode, and disconnect the main positive and negative cables from the battery pack. These steps help minimize battery drain and prevent potential damage.
Yes, the FORM Charge charger will work with AGM batteries.
Yes. Find a suitable location on the equipment and mount it using the appropriate hardware. Find the ends of the electrical series on your batteries. Attach the Red lead (marked with red heat Shrink) to the battery Positive (+). Attach the Black lead (marked with black heat shrink) to the battery Negative (-).
Follow these steps to properly mount your onboard charger.
